Description
Main
Sensor: CMOS 1280x720
Magnification, x: 4.5 – 18 (x4 zoom)
IR Illuminator wavelength, nm: 850 (long-range)
Detection range, m: 550
Sensor
Type: CMOS
Resolution, pixels: 1280x720
Optics
Objective lens: F50/1.2
Magnification, x: 4.5 – 18
Field of view (HxV), degrees / m @ 100 m: 6.2x4.7 / 10.9x8.2
Eye relief, mm: 50
Display
Type: AMOLED
Resolution, pixels: 1024x768
Infrared Illuminator
Emitter: LED
IR wavelength, nm: 850 (long-range)
Range Performance
Detection range, m: 550
Reticle
Click value, H/V, mm at 100 m: 10
Click range, H/V, mm at 100 m: 2000 / 2000
Number of preloaded reticles: 10+
Video Recorder
Video / photo resolution, pixel: 1024x768
Video / photo format: .mp4 / .jpg
Built-in memory, Gb: 16
Environmental Characteristics
Degree of protection, IP code (IEC60529): IP?7
Operating temperature range, °?: -25 – +50
Weight & Size
Dimensions, mm: 370x73x74
Weight, kg: 0.83
Power Supply
Output voltage, V: 3.1 - 4.2
Battery type: Li-Ion Battery Pack IPS5
Capacity, mAh: 5000
Operating time on battery pack (at t=22°C), h *: 4 (max consumption mode) – 8 (max consumption mode)
External power supply: 5V
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo), Joules: 6000
Shock resistance on the smooth-bore rifles, caliber: 12
Wi-Fi
Frequency: 2.4GHz
Standard: 802,11 b/g/n
Line-of-sight reception range, m: 15
|
|
|
|
|
|
|
